ATEX, IECEx certifications

Voltage: Max. AC800V 50/60Hz
Current: 415A
Degree of Protection: IP66
Hazardous Ratings: Zone 1/2, Zone 21/22

Voltage: Max AC1100V
Current: 24A/32A/41A/57A/76A/115A/126A/184A/218A/265A/350A
Degree of Protection: IP66
Hazardous Ratings: Zone 1/2, Zone 21/22

● EX Certified for Zones 1 and 2 (gas), 21 and 22 (dust)
● Modular
● Stackable
● Exceptionally durable
● Waterproof and dustproof
● Compact and lightweight
● Multiple options
● Plug and Play
● MCB and RCD Protection
● Externally Resettable
● Flexible and Movable

● EX Certified for Zones 1 and 2 (gas), 21 and 22 (dust)
● Modular
● Stackable
● Exceptionally durable
● Waterproof and dustproof
● Compact and lightweight
● Multiple options
● Plug and Play
● MCB and RCD Protection
● Externally Resettable
● Flexible and Movable

Voltage: Max .AC690V
Current: 24A/32A/41A/57A/76A/125A
Degree of Protection: IP66
Hazardous Ratings: Zone 1/2, Zone 21/22

Enclosure: 304 stainless steel, 316L stainless steel
Ambient temperature: -60°C to +60°C / -60°C to +40°C
Hazardous Ratings: Zone 1/2, Zone 21/22

Dimensions: 443x267x162mm(17.44x10.51x6.38inch)
Hazardous Ratings: Zone 2

Connection Thread: Metric thread NPT or other thread(optional)
Thread Pitch: Metric thread: 15mm
Other thread: Customizable
Ambient Temperature: -60°Cto +70°C
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Gauge pressure
Measuring range: 10kPa-10MPa, please refer to the
ordering information chapter
Output signal: 4-20mA, 4-20mA+HART,
customer Modbus-RTU/RS485, customer
Reference accuracy: ±0.2% URL, ±0.5% URL
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Absolute pressure
Measuring range: 20kPa-1 MPa, please refer to the
ordering information chapter
Output signal: 4-20mA, 4-20mA+HART, customer
Reference accuracy: ±0.2% URL, ±0.5% URL
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Gauge & Absolute pressure
Measuring range: 10kPa -3MPa
Output signal: 4-20mA,4-20mA+HART, customer
Reference accuracy: ±0.5% F.S. optional ±0.2% F.S.
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Differential pressure
Measuring range: 10kPa-1MPa, please refer to the
ordering information chapter
Output signal: 4-20mA, 4-20mA+HART, Modbus-RTU/RS485, others
Reference accuracy: ±0.2% URL, ±0.5% URL
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Differential pressure
Measuring range: 10kPa-1MPa, please refer to the ordering information chapter
Output signal: 4-20mA, 4-20mA+HART, Modbus-RTU/RS485others
Reference accuracy: ±0.2% URL, ±0.5% URL
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Gauge pressure
Measuring range: 2kPa-40MPa, please refer to the ordering information chapter
Output signal: 4-20mA, 4-20mA+HART,
1-5VDC low power consumption,
Modbus-RTU/RS485 customer
Reference accuracy: ±0.1%URL, optional ±0.075%URL
Hazardous Ratings: Zone 1/2, Zone 21/22

Pressure types: Absolute pressure
Measuring range: 20kPa-10MPa,
please refer to the ordering information chapter
Output signal: 4-20mA, 4-20mA+HART,
1-5VDC low power consumption,
Modbus-RTU/RS485 customer
Reference accuracy: ±0.2%URL, optional ±0.075%URL
Hazardous Ratings: Zone 1/2, Zone 21/22
